A workflow remembers where the request got to#

A workflow, also called a graph, connects software steps such as choosing an action, sending it, waiting for feedback, and reviewing the result. One running request is an execution. Its objective is the outcome the user or system asked it to achieve.

Saving an execution lets it pause without losing that objective. A saved wait means the request stays open while something else happens—for example, while the robot moves or another software worker returns an answer. When the needed result arrives, the workflow can continue from its saved position.

LangGraph schedules the connected steps. A SQLite database for the selected profile retains the objective, events in order, completed step outputs, saved checkpoints, and actions waiting to be sent. A checkpoint records where the workflow can resume; completed outputs are kept without being overwritten.

A robot sub-workflow shares the parent execution. A specialist agent is a software worker assigned a finite job, not another robot. It runs through the Work Coordinator and returns a result linked to the parent request. The parent can remain open while these smaller jobs finish or eligible work retries.

Robot Status displays the execution’s decisions. Recent conversation provides context, and memory supports recall, but the saved execution keeps the active objective. Status now carries the execution’s actual lifecycle: an old failed, cancelled, or completed request remains history instead of appearing as a new request’s current goal. A fresh command result updates the action facts even when the model makes no change to the objective.

Sending an action without losing track of it#

The Work Coordinator accepts and schedules finite jobs, manages recovery, and determines which process may control the body. Saving an intention to act and accepting that job are separate steps; both need records.

The workflow’s Environment Bridge Out step saves the intended action with its checkpoint. The Environment Bridge maintains MetaHuman’s connection to external devices. Ainekio’s adapter translates the action into a robot command, and its authenticated gateway carries that command to the body. The firmware then validates and executes it.

Saving before dispatch matters when a process stops unexpectedly. Local adapter changes retain action records, reject an ID reused for different content, and check the current Coordinator’s authority before sending. They can redeliver acknowledgements and results without issuing the physical command again.

If an interruption leaves it unclear whether a movement happened, recovery must keep that uncertainty and reconcile it before deciding on further movement. “Body ownership” in the implementation refers to the software process allowed to send commands; it does not refer to ownership of the physical robot.

The September 8 gateway repair keeps tracking a dispatched command beyond the old fixed 30-second wait. Recovery follows its saved gateway instance, robot session, and sequence rather than sending it again. Controlled integration checks show a late result settling the original execution and releasing the queued next action. That host repair still needs a gateway restart and live verification.

Reviewing the result and continuing#

The input router, or orchestrator, treats incoming user input as a new request, a correction, or a cancellation. The Environment Action Selector chooses conversation, a supported body action, or a limited generated motion plan. Parsing and firmware checks constrain what can actually run.

After dispatch, the workflow waits for the appropriate feedback:

1. Action Result interprets whether the action completed, failed, was rejected, or was interrupted.
2. Goal Review, when an objective remains, asks whether the result satisfies it and can choose a robot step, another available specialist, or no new work.
3. The saved execution finishes, waits for input, or continues with another step.

For “stand,” a command result may be enough. For the better-light example, review needs a current image linked to the movement. A rejected, expired, or cancelled action can return without waiting for an image from movement that never happened. The command guide explains these result states in more detail.

Specialist work now carries the actual task brief into the worker, and its answer returns to the waiting parent request. A failed worker returns failure; an intermediate output is not substituted for a completed answer. This lets the next decision use what the specialist actually found while keeping the original request intact.

Connecting a Desire to a result#

MetaHuman’s optional Desire system tracks possible work through planning, review, execution, and outcome review. The latest changes connect its approved robot steps to the same durable workflow used for ordinary body actions.

Each step reloads the saved reviewed plan and carries the Desire ID, plan version, step number, and expected outcome. Its result returns to Agency, the Desire lifecycle owner, before the plan advances. A failed or unsatisfied step stops progress; an uncertain effect needs evidence before another attempt. General Goal Review does not expand the admitted Desire step into open-ended robot work.

Robot Status retains compact awareness of pending desires. Full motivations and plans are loaded for the selected Desire work, so an unresolved idea does not act as a standing instruction in every robot decision. The autonomy guide explains the practical difference.

Keeping conversation connected to the action#

Robot microphone recordings enter through the Environment Bridge and Whisper, which transcribes speech to text. A camera image with the same originating ID can join that conversation turn. The turn then uses the same submission and context handling as other MetaHuman interfaces.

Current context work keeps the latest user instruction within the configured history window so intervening assistant actions do not crowd it out. The saved execution separately retains the objective and its events, allowing a correction to affect ongoing work instead of disappearing among status messages.

For a spoken response, synthesis produces audio and delivery sends it through the Bridge and Ainekio’s paced speaker output. Producing audio, playing it, and completing the broader request are separate outcomes. Playback results, interruptions, and delivery failures are recorded accordingly. See listening and speech for that full path.

What changes for V2, and what still needs testing#

MetaHuman will continue asking for actions while the body changes from an ESP32-S3 with eight servos to an ESP32-P4 with twelve. The current motion contracts describe eight joints. New joint names, motion assets, validators, advertised features, camera/audio support, and communication must agree before V2 movement becomes available.

The September 8 reviews record saved-graph tests of specialist returns, user corrections, cancellation, result ordering, and recovery in a fresh process. The later Desire suite also checks ordered robot steps, altered instructions, unsatisfied outcomes, and closure after outcome review. These use controlled provider responses and establish behavior for their recorded snapshots.

The live run establishes that part of the redesigned path was operating; it does not validate the later repairs. Deployed recovery, direct stop, model judgment, and repeated physical runs remain to be checked. The status report separates the dated test results from live observations and remaining faults.
